Nanlux Evoke 5000B Set
Nanlux Evoke 5000B Set
Nanlux Evoke 5000B Set
Nanlux Evoke 5000B Set
Prices per day excluding vat. Vat will be charged according local law.

1 Day 2 Days 3 Days 4 Days 5 Days 6 Days 7 Days


The Nanlux Evoke 5000B is a 5000W bi-color LED spotlight featuring a 2700–6500K CCT range and ±80 green/magenta adjustment. It delivers up to 555,250 lux at 1 m (5600K) with CRI 97 / TLCI 98. With IP66 weatherproofing, integrated Nebula B4 Light Engine, 12 built-in effects, and versatile control options (DMX, CRMX, app), it's ideal for film and TV productions.

  • 5000W Bi-Color LED Monolight
  • Color Temperature: 2700K to 6500K
  • ±80 Green/Magenta Adjustment
  • Output at 1 m (5600K, 45° reflector): 555,250 lux
  • Output at 5 m (5600K, 45° reflector): 22,210 lux
  • Beam Angle: 95° (bare), 45° (with reflector)
  • CRI: 97
  • TLCI: 98
  • TM-30 Rf/Rg: 96/102
  • SSI: 85 (3200K), 74 (5600K)
  • Dimming: 0.1% to 100%, adjustable in 0.1% steps
  • Flicker-free up to 10,000 fps
  • 12 built-in customizable lighting effects
  • Control: Onboard (3 knobs, 4 buttons, 4.3" screen), Wired controller, Nanlink App, LumenRadio CRMX, Bluetooth, DMX/RDM (5-pin XLR), Art-Net/sACN (RJ45)
  • Input Voltage: 100–240 VAC, 50/60 Hz
  • Max Power Consumption: 5200W
  • Cooling Modes: Smart (44 dB), Full Speed, Low Speed, Pause, Off
  • Housing: High-strength magnesium alloy
  • Weight (without yoke): 43.12 kg / 95.06 lb
  • Mount: 1-1/8" stud with yoke
  • IP66 certified (dust- and water-resistant)
  • NL mount with PosiTight system
  • Included: Reflector, yoke, AC cable, USB drive, wired controller
  • Compatible with NL mount accessories (e.g. Fresnel, softbox)
Detail Value
Color Engine Nebula B4 Bi-color + GM
CRI 97
Kelvin minimal 2700
Kelvin maximal 6500
Power Consumption (W) 50000
App for remote operation Nanlink
Type of Lightsource spot
IP Rating IP66
Lumenradio build in CRMX build in
Powersupply (A) 32AH
